The Row Crop Spreader Series is designed for growers who need wide swath spreading of lime and fertilizer, and want the ability to top-dress on standing crops. Fully adjustable axle allows new wheel spacing should your row width change in the future. All RC spreaders come standard with Cor-Ten HSLA weathering steel hoppers. The RC-8010 and 1516 are designed for spreading damp stockpiled lime. The steep 53 degree side slopes and 4"drop pan combination prevent bridging. It will also spread fertilizer, compost, litter and more.
The larger volume RC-8012 and 1520 are designed for 8 and 15 tons of fertilizer while maintaining the ability to spread other materials. The spreader comes "variable rate ready", so just needs to be hooked up to the monitor in your tractor.
STANDARD
- 8 and 15 ton capacities
- Cor-Ten steel hopper
- 7 gauge Cor-Ten® steel pan
- Fertilizer kit for rates down to 125 lbs/acre
- 8 ton: 72"-120", 15 ton: 90"-152"
- Row crop tires
- Plug to tractor hydraulics
- Top driven spinners
- Electric gate with indicator
- Unibody, fully welded design
- Structural steel frame
- 4" drop pan
- Extra body braces
- 53-degree body sides
- 24" slat style chain
- CAT IV hitch
OPTIONAL
- Flotation tires
- Lights
- Tarp
- 304 Stainless steel hopper
- GPS
MATERIALS SPREAD
- Stockpiled (wet or damp) Ag lime
- Fertilizer
- Gypsum
- Marl
- Compost
- Poultry manure
- Sand
- Crushed shells
| Models | RC8010 | RC8012 | RC1516 | RC1520 |
|---|---|---|---|---|
| Max. load | 8 tons | 8 tons | 15 tons | 15 tons |
| Hopper volume | 177 cu.ft. | 331 cu.ft. | 300 cu.ft. | 510 cu.ft. |
| Hopper side slope | 53 deg. | 45 deg. | 53 deg. | 45 deg. |
| Hopper lenght | 10 ft. | 12 ft. | 16 ft. | 20 ft. |
| Hopper width | 78 in. | 102 in. | 88 in. | 102 in. |
| Hopper depth | 45 in. | 59 in. | 51 in. | 55 in. |
| Overall lenght | 19.5 ft. | 21.5 ft. | 27 ft. | 29.5 ft. |
| Overall width | 87-137 in. | 102-136 in. | 105-180 in. | 105-180 in. |
| Overall height | 106 in. | 115 in. | 114 in. | 118 in. |
| Wheel track (center) | 72-120 in. | 72-120 in. | 90-152 in | 90-152 in. |
| Row crop tires (15" wide) | 380/90R46 | 380/90R46 | 380/90R46 | 380/90R46 |
| Flotation tires (28" wide) | — | — | 710/70R38 | 710/70R38 |
| Weight | 5,800 lbs. | 6,200 lbs. | 9,100 lbs. | 12,200 lbs. |
